Specifications

• Mfr Part Number: D16-THUNDERBOLT 3
• Feature
  • Lightninging-Fast
  • Enjoy Rapid Video Workflows
  • Compact design
  • Peace as a priority
  • Large Storage Capacity
  • High Scalability
  • Thunderbolt 3 and Thunderbolt 2 Compatibility (for Mac only)
  • Create the Smartest Workspace
  • Multiple RAID Supports
  • Professional and Safe
  • The Ideal Companion for All Professionals
• Storage
  • Disk Slot Number:16
  • Compatible Disk Types: 3.5" SATA/SAS HDD, 2.5" SATA HDD, 2.5" SATA SSD
  • File System:FAT 32, FAT 16, NTFS, EXT4, APFS, Mac OS
  • Maximum Internal Raw Capacity:288 TB (18 TB drive x 16) (Capacity will vary along with the RAID type)
  • RAIDs Supported:SINGLE DISK,JBOD,RAID 0,RAID 1,RAID 5,RAID10,RAID 6,RAID 50
  • RAID Manager Software Language: English, Chineses, Japanese
  • Hardware RAID, RAID Manager Software, RAID Online Expansion, RAID Migration, RAID Auto-rebuilding, Drive Hot Swap, HDD Sleep, HDD S.M.A.R.T. Inspection, Sector Inspection and Parity Check, SSD Cache, Daisy Chain, HDD NCQ Technology, Alert Notice, Event Log
• External Ports:
  • USB: USB HOST 3.1 Gen 2
  • Thunderbolt: 40Gb Thunderbolt 3 x 2
  • DP Interface: DP 1.4 x 1
  • Power Socket: AC IN 220V
• Reading/writing Speed (max.):
  • Reading Speed (max.)

    - Read: 2817MB/secRAID0, fully loaded with SSD(s)for win 10 );Read: 2786MB/secRAID0, fully loaded with WD Ultraster 10T HDD(s) for win 10 )

    - Read: 2660MB/secRAID5, fully loaded with SSD(s) for win 10 );Read: 2607MB/secRAID5, fully loaded with WD Ultraster 10T HDD(s) for win 10 )

    - Read: 1920MB/secRAID5, fully loaded with SSD(s) for Mac );Read: 1594MB/secRAID5, fully loaded with WD Ultraster 10T HDD(s) for Mac )
  • Writing Speed (max.)

    - Write: 2022MB/secRAID0, fully loaded with SSD(s) for win 10 );Write: 1550MB/secRAID0, fully loaded with WD Ultraster 10T HDD(s) for win 10 )

    - Write: 1070MB/secRAID5, fully loaded with SSD(s) for win 10 );Write: 820MB/secRAID5, fully loaded with WD Ultraster 10T HDD(s) for win 10 )

    - Write: 1090MB/secRAID5, fully loaded with SSD(s) for Mac );Write: 1015MB/secRAID5, fully loaded with WD Ultraster 10T HDD(s) for Mac )
• System fan: 90mm x 90mm x 25mm 4PCS
• Noise Level: 55dB(A) (Noise testing environment: Fully loaded Seagate EXOS 8TB ST8000NM000A hard drive(s) in the reading state)
• Power Supply:
  • Power Supply: 550W
  • AC Input Voltage: 100V to 240V AC
  • Current Frequency: 50/60 HZ, Single Phase
  • Power Consumption: 230W(Fully loaded Seagate EXOS 8TB ST8000NM000A hard drive(s) in the reading state)
• Environment Temperature:
  • Working Temperature: 5C ~ 40C (40F ~ 104F)
  • Storage Temperature: -20C ~ 60C (-5F ~ 140F)
  • Relative Humidity: 5% ~ 95% RH
• Supported OS: Windows OS, Mac OS
• Certificate: CE, FCC, CCC
• Environment: RoHS compliance
• Package Contents:
  • Host unit (x1)
  • Power cord (x1)
  • Thunderbolt 3 cable (40Gbps) x 1
  • Quick Installation Guide (x1)
  • Screws (several)
  • Limited Warranty Note x 1
• Size (HxWxD): 348 x 160 x 498 mm
• Warranty: 2 years
